RG 59 B/U Solid Coax Cable

Stock Code:
BCX2140-300
Price:
$0.00 excl GST

Description

RG 59 B/U MIL-17-C 75 Ohm Coaxial Cable

CONSTRUCTION :

Type ---------------- MIL-C-17 Type.
Conductor --------- 1 x 0.584mm ( Annealed copper ).
Insulation ---------- Solid Low Density Polyethylene.
Insulation O/D ---- 3.70mm.
Shield --------------- BC 0.16mm 16 x 7 = 112 Net ( 95% Coverage ).
Jacket --------------- Flame Retardant V75 Non Migrating PVC.
Jacket Colour ----- Black.
Jacket O/D --------- 6.15mm.
Impedance --------- 75 Ohm.

PRINTING: White Printing on the Black Cable Jacket.
Printing to be repeated at approximately 0.05m intervals.

RADUM RG59 B/U MIL-C-17 Type 75 Ohm COAXIAL CABLE.

PACKING: Note ---- The Diameter of the Centre hole in the drums MUST
be at least 30mm or the shipment will be rejected.

100m Plastic or Wooden Drum ( 2 by 100m drums per cardboard Box).
500m Wooden Drum ( 1 by 500m drum per cardboard Box).

SHIPPING MARK: ---- RADUM in a Triangle.

LABELLING: ---- On the outside of each drum Flange.

On the 100m Flange --- On the 500m Flange ---

BCX2140-100 BCX2140-500
RADUM RG59 B/U RADUM RG59 B/U
75 Ohm Coaxial Cable 75 Ohm Coaxial Cable
Length – 100m Length – 500m

LABELLING: ---- On the outside of each packing Box.
